The Harley-Davidson® Breakout™ is Back for 2023 and Better than Ever

A decade after its first appearance, Harley-Davidson® reintroduces the Breakout™ again. We here at Barnes believed the raked out cruiser was gone for good after 2020, much to our dismay, but we now know it just went on a brief hiatus so that Harley-Davidson® could perfect it. And we couldn’t be happier! Breakout™ has been completely reinvented and is better than ever. So what’s new?

  1. 117 powertrain. Back in 2020, Breakout™ left us with a 103 cubic inch engine. It returns in 2023 with much more power and ferocity, thanks to the new 117 cubic inch powertrain, the largest engine Harley-Davidson® offers from the factory.
  2. 5 gallon tank. When we last saw Breakout™, it had a 3.5 gallon tank. This thirty percent increase was necessary with the larger powertrain. To feed this hungry pony, you need more gas! Yet Harley-Davidson® was mindful of the weight and kept the size in the mid-range so as to not slow you down.
  3. Paint finishes. The 2023 Breakout™ comes in 4 colours – Vivid Black, Black Denim, Baja Orange, and Atlas Silver Metallic. All four of these colours have unique finishes and graphic styling that serve to elevate the paintwork.
  4. Handlebars. A new handlebar riser and polished stainless steel handlebar is 3/4-inch taller than before for improved rider reach to controls.


Wake up your senses while stealing glances.

Wondering if Breakout™ is for you? This model flexes muscle and flashes bright chrome styling over its long-and-lean chopper profile, and instantly grants you bragging rights with its massive engine. Still not convinced? These details might help you decide. If you’re a fan of the following features, you’ll be a fan of Breakout™.

Description:

  • Stretched riding position
  • Forward foot controls
  • Passenger seat
  • Low to the ground

Overview:

  • Milwaukee-Eight™ 117 V-Twin Powertrain
  • Muscular style and performance
  • New chrome finishes


Key Features:

  • Bright New Look
    Chrome Finishes: Fender supports, side covers, muffler shields, turn signals, mirrors, Heavy Breather intake
  • Chassis
    An improvised Harley-Davidson® Softail™ chassis reduces weight without sacrificing stiffness while maintaining the classic look of a hard tail
  • Reshaped Seat
    A new shape to the seat helps accommodate the 5-gallon fuel tank
  • 2-Into-2 Exhaust
    High-performance 2-into-2 offset shotgun exhaust for smooth and broad exciting mid-range torque with a stirring tone
  • Wheels
    26-spoke cast aluminum wheels; Gloss Black finish with machined details; 21-inch front/18-inch rear diameter

Obscene Performance:

  1. Milwaukee-Eight 117 V-Twin Engine
    Get instant bragging rights on the street with this precision air/oil cooled engine that is the new pinnacle of torque and displacement in factory-installed, regular-production Harley-Davidson® powertrains.
  2. Heavy Breather
    High-performance, tuned Heavy Breather intake with forward-facing exposed filter element flows more air into the engine to help produce exciting mid-range torque, and gives the motorcycle added hot rod presence.


Styling and power that lets you be seen, then be gone.

Colours

Vivid Black:


Black Denim:


Baja Orange:


Atlas Silver Metallic:


The 2023 Breakout™ 117 is going to be a wildly popular choice this year. So if you find yourself craving a ride, get in touch with us here at Barnes Harley-Davidson as soon as possible so that we can reserve once for you. Click here to reserve your Breakout™, or take a look at our 2023 in-stock inventory here.

Every night is bike night.

Detailed Specs

Dimensions:

LENGTH: 2,370 mm

SEAT HEIGHT, UNLADEN: 665 mm

GROUND CLEARANCE: 115 mm

RAKE: 34

TRAIL: 145 mm

WHEELBASE: 1,695 mm

TIRES, FRONT SPECIFICATION: 130/60B21,63H,BW

TIRES, REAR SPECIFICATION: 240/40R18,79V,BW

TIRE, TYPE: Michelin Scorcher “11” front and rear

FUEL CAPACITY: 18.9 l

OIL CAPACITY (W/FILTER): 4.7 l

WEIGHT, AS SHIPPED: 296 kg

WEIGHT, IN RUNNING ORDER: 310 kg

Engine:

ENGINE: Milwaukee-Eight 117

BORE: 103.5 mm

STROKE: 114 mm

DISPLACEMENT: 1,923 cc

COMPRESSION RATIO: 10.2:1

FUEL SYSTEM; Electronic Sequential Port Fuel Injection (ESPFI)

EXHAUST: 2-into-2 staggered; catalyst in muffler

Performance:

ENGINE TORQUE TESTING METHOD: J1349

ENGINE TORQUE: 167 Nm

ENGINE TORQUE (RPM): 3500

HORSEPOWER: 101 HP / 75 kW @ 4750 rpm

LEAN ANGLE, RIGHT (DEG.): 26.8

LEAN ANGLE, LEFT (DEG.); 26.8

FUEL ECONOMY TESTING METHOD: Estimated City/Hwy

FUEL ECONOMY: 5 l/100 km

Drive Train:

PRIMARY DRIVE: Chain, 34/46 ratio

GEAR RATIOS (OVERALL) 1ST: 9.311

GEAR RATIOS (OVERALL) 2ND: 6.454

GEAR RATIOS (OVERALL) 3RD: 4.793

GEAR RATIOS (OVERALL) 4TH: 3.882

GEAR RATIOS (OVERALL) 5TH: 3.307

GEAR RATIOS (OVERALL) 6TH: 2.79

Chassis:

FRONT FORK: Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring

REAR SHOCKS: Hidden, free piston, coil-over monoshock; 43mm stroke; toolless hydraulic preload adjustment

WHEELS, FRONT TYPE: Gloss black, 26-spoke cast aluminum

WHEELS, REAR TYPE: Gloss black, 26-spoke cast aluminum

BRAKES, TYPE: Front and rear black, Split 7-spoke floating rotors

BRAKES, CALIPER TYPE: 4-piston fixed front and 2-piston floating rear

Electric:

LIGHTS (AS PER COUNTRY REGULATION), HEADLAMP, TAIL/STOP, FRONT SIGNAL LIGHTS: All LED, low beam, high beam and signature position lamp; Incandescent bullets

GAUGES: 2.14-inch viewable area LCD display with speedometer, gear, odometer, fuel level, clock, trip, range and tachometer indication

Rider Safety Enhancements:

ANTI-LOCK BRAKE SYSTEM (ABS): Included

TRACTION CONTROL SYSTEM (TCS): Included


Pricing Info

Pricing:

VIVID BLACK: $26,549

COLOUR: $27,199

ABS OPTION: Standard

TRANSPORT: $850

SURCHARGE: $800

Written by Raven Egan
